8 staton shrinking machine GT-JY8

For short length 1m or less tubular electric heater MgO compaction, use our customized  Heater Roll Compress Equipment GT-JYC8.

Diameter range after compacted: Φ3.0 ~ Φ9.0mm;

diameter suggested start: Φ10mm or less.

1. It’s made of one-piece casted iron machine body, and done with 72 hours of tempering high temperature heat treatment for better rigidity and strength much strong in long lasting usage;

2. The press roller spindle box and diameter-adjusted sliding block are done by wire-cutting ~ that ensure accuracy within 0.03mm. And with fine-adjusting dial, it's easy to return zero for re-adjustment.

3. With block detecting sensor, when blocking happened it stop automatically.

4. Upgrade with dust remove device, automatic oil drop cooling device;

5. Gearbox speed option: uniform speed, or un-uniform speed

Work with our  Heater Roll Compress Equipment for tubular heater manufacturing efficiently.
